Ch. 6. Fluid Imaging in a Droplet Sec. 6.1. Nomenclature
The cantilever holder can be used for contact mode and AC mode imaging in fluid. It has a built-in
piezoelectric actuator for driving cantilevers at resonance. Please refer to Chapter 7 on page 75 for
specifics on iDrive imaging only.
6.1. Nomenclature
Please refer to
Figure 6.1 on page 54.
Figure 6.1.: Droplet Cantilever Holder nomenclature.
6.2. Parts List
Asylum Inventory Number 901.738.1
Itm Part # Item Description Qty Picture
1
004. SETS
<#80 x
0.063>
CUP
0-80 x 1/16” set screw, cup
point.
6
BETA
