The Environmental Scanner is included with the Cypher model ES AFM. Please review the parts lists
below and the basic imaging tutorial in
Chapter 11 on page 130.
10.1. Parts list
The following table describes all the tools and other items included with your Environmental Scanner.
Please refer to the part number when seeking support or ordering replacements.
Itm Part # Item Description Qty Picture
1* 290.147
Scalpel Handle. Used to attach
liquid perfusion tubing to the
cantilever holder.
1
2* 290.148
No. 15 scalpel blade. Used to
attach liquid perfusion tubing to
the cantilever holder.
10
3 290.130
1/16” Hex Driver. Used to
remove the cantilever holder
(see
Step 6 on page 132) and
chamber bodies (see Step 2 on
page 166).
1
The scale in the photos is in cm and mm.
