Operating Instructions Xenotest
®
150 S+
5.4 Irradiation system
Fig.12: The samples on the sample carousel 3 revolve around the xenon lamp and
the filter system so that they are irradiated,
The irradiation intensity (or the irradiator rating) is adjusted on the basis of the filter
system employed.
• Adjustment range: 65 % to 100 %
The Xenotest
®
150 S+ offers the special function of a rotating mode:
With the rotation option activated, the samples 1 on the sample holder 2 are also
rotated by 180° around their axis during each revolution of the carousel.
With identical irradiator rating (in %), the irradiation intensity at sample level is nearly
identical in synchronous and in rotating mode.
5 Functional description
Fig. 12
