Atlas XENOTEST 150 S+ User Manual

23
Operating Instructions Xenotest
®
150 S+
Tab. 01
5.3 Overview of the filter systems
Exterior cylinderAbsorption filter
Special UV glass
IR filter, set of 7, (green cut edge) Special UV glass
IR filter, set of 6, (green cut edge)
UV filter, 1 piece (black filter)
Tab. 02 - 03: Relative spectral energy distribution (RSP = Relative Spectral Portion)
in the wavelength range of 300 - 400 nm, when using different filter systems:
5 Functional description
Tab. 02 - 03
Wavelength RSP RSP
<300 nm
0
0.29
300 - 320 nm 0.11 0.1 - 2.8
320 - 360 nm 21.6 23.8 - 35.5
360 - 400 nm 76.1 62.4 - 76.2
290 - 400 nm 100 100
7IR SO 105-B02
Wavelength RSP RSP
<290 nm 0 0.15
290 - 320 nm 0.76 2.6 - 7.9
321 - 360 nm 24.3 28.2 - 38.6
361 - 400 nm 72.82 55.8 - 67.5
290 - 400 nm 100 100
6IR 1UV SO 105-B04
