Operating Instructions Xenotest
®
150 S+
7.6 Test program settings
The program control of the Xenotest
®
150 S+ allows the free programming of 10 test
programs. The program parameters are entered in prestructured program steps using
the instrument touch screen.
NOTE - Software documentation:
The programming of the test programs is described in the separate
software documentation.
Tab. 06 / 07: The tables contain possible settings for the Xenotest
®
150 S+ for the
pertaining standards. The values given refer to the dry phase.
NOTE - Determination of the radiation intensity:
** The percentage value for the irradiance was determined under
the defined conditions using a new irradiator. The actual value varies
with increasing lamp age.
7 Operation
Tab. 06
Tab. 07
Description
ISO 105-B02
Normal conditions
X 150 S+
Operation Rotating operation Rotating operation
Filter 7 IR 7 IR
Irradiance 42 W/m² (WL) ~76 % **
Test chamber temperature ---------- 35 °C
Blower speed ---------- ~700 rpm
Relative humidity
Lightfastness 5
on red test coloring
Reference value 40 %
determine exact setting
using test coloring
Black standard temperature 50 °C max
50 °C max above blower
speed
Blackboard temperature 45 °C max 45 °C max
Description ISO 105-B04 X 150 S+
Operation Rotating operation Rotating operation
Filter 6 IR / 1UV 6 IR / 1UV
Irradiance 42 W/m² ~65 % **
Test chamber temperature 40 °C max in dry phase 41 °C
Blower speed --------- ---------
Misting cycle (on/off) 1/29 min 1/29 min
Black standard temperature 60 °C max 60 °C max in dry phase
