43
Operating Instructions Xenotest
®
150 S+
Printer settings:
The following printer parameters have been preset at the factory:
Printer Interval NO
Printer Address 00--Print Always
Data Format 8 NO Parity
Baud rate 9600
Interface Serial
Character Set National Language
Characters/line 40
Print Format Normal
Print Strength a.....+.....a
Mode Online
Changing printer modalities:
The factory settings can be adjusted to the customer's specific needs.
1. Open the parameter menu:
Press and hold down the MENU/SELECT key on the printer for approx 3
seconds.
The following message appears on the operator panel display:
ACTUAL PARAMETER?
PRESS ENTER
2. To print the voltagely valid parameters:
Press the LINE FEED/ENTER key on the printer.
The following message appears on the operator panel display:
CHANGE OF PARAMETERS?
3. To change the parameters:
Simultaneously press and hold down the LINE FEED/ENTER and MENU/SE-
LECT keys on the printer for approx. 4 seconds.
The parameter list appears on the operator panel display.
4. To change a value, press the MENU/SELECT key.
Enter the desired value and confirm your entry by pressing the MENU/SELECT
key.
Use the arrow keys on the instrument operator panel to switch between the pa-
rameter lines.
5. To exit the parameter menu:
Simultaneously press and hold down the LINE FEED/ENTER and MENU/SE-
LECT keys on the printer.
If you do not manually exit the parameter menu, the control program will auto-
matically exit it after 3 minutes.
6 Start-up
