AudioCodes Mediant 1000B - Connecting to Power

Hardware Installation Manual 5. Cabling the Device
Media Gateways & SBCs 59 Mediant 1000B Gateway & E-SBC
5.8 Connecting to Power
The procedure below describes how to connect the device to the AC power supply. You
can install up to two Power Supply modules (Power 1 and Power 2) for power redundancy.
For installing the Power Supply modules in the chassis, see Section 6.2.4 on page 74.
Warnings:
• Units must be connected (by service personnel) to a socket-outlet with a protective
earthing connection.
• Use only the AC power cord supplied with the device.
• When using only one Power Supply module, the second AC power socket on the rear
panel is covered by a plastic sticker. Please do not remove the sticker and connect
anything to this power socket. Remove the sticker only when two Power Supply
modules are used.
Avertissements:
• L’appareil doit être branché à une prise murale à condition qu’elle soit mise à la
masse.
• Utilisez uniquement le cordon AC fourni avec l’appareil.
ご注意
本製品に添付の電源ケーブルは、Mediant 1000B Gateway & E-SBC
に専用設計されているため、汎用性がありません.
本電源ケーブルを他の機器に使用されないよう、ご注意ください.
Note: For dual power supply:
• Connect each Power Supply module to a different AC supply circuit.
• The two AC power sources must have the same ground potential.
• Configure the device to send an SNMP alarm (acPowerSupplyAlarm) upon a failure
or removal of any of the installed Power Supply modules. For enabling this
functionality, use the ini file parameter, Mediant1000DualPowerSupplySupported. For
more information, refer to the User's Manual.
