AudioCodes Mediant 1000B - Table A-3: RJ-45 Connector Pinouts for Gigabit Ethernet Interface

Hardware Installation Manual A. Open Solution Network Server Platform
Media Gateways & SBCs 79 Mediant 1000B Gateway & E-SBC
Item # Label Description
5
Reset pinhole button.
 To warm reset the operating system of the OSN server (i.e.,
power remains on): Press and then immediately release the
button (less than five seconds). The LED indications are as
follows (see Section A.2.1.2 for LED locations):

Upon reset:
LED #1: On (solid green)
LED #2: On (solid red)

End of reset: LED #1 remains on (solid green); all other
LEDs off.
 To cold (hard) reset the OSN server (i.e., powers off and
then powers on): Press the button for longer than five
seconds and then release. The LED indications are as
follows (see Section A.2.1.2 for LED locations):

Upon reset:
LED #1: On (solid green)
LED #2: On (solid red)
LED #5: On (solid blue)

End of reset: LED #1 remains on (solid green); all other
LEDs off.
The RJ-45 connector pinouts for the Gigabit Ethernet interface are listed in the table below:
Table A-3: RJ-45 Connector Pinouts for Gigabit Ethernet Interface
Pin 100Base-Tx 1000Base-T
I/O Signal Signal Function
1
O Tx+ I/O BI_DA+
2
0 Tx- I/O BI_DA-
3
I Rx+ I/O BI_DB+
4
I/O BI_DC+
5
I/O BI_DC-
6 I
Rx- I/O BI_DB-
7
I/O BI_DD+
8
I/O BI_DD-
