AUMA AC 01.2 - Page 144

DescriptionSignal
Collective signal 19:
This signal can be configured (parameter Fault (Cfg) M0880) and comprises a combination of the following
signals:
●
Configuration error
●
Config. error REMOTE
●
Internal error
●
Torque fault CLOSE
●
Torque fault OPEN
●
Phase fault
●
Incorrect phase seq
●
Mains quality
●
Thermal fault
●
Fault no reaction
●
Wrn input AIN 1
●
Wrn input AIN 2
●
Incorrect rotary direct.
●
DMF fault OPEN
●
DMF fault CLOSE
●
FQM collective fault
Fault (configurable)
Collective signal 20:
This signal can be configured (parameter Warnings (Cfg) M0881) and comprises a combination of the
following signals:
●
Config. warning
●
Internal warning
●
24 V DC external
●
Wrn op.mode run time
●
Wrn op.mode starts
●
Failure behav. active
●
Wrn input AIN 1
●
Wrn input AIN 2
●
Wrn setpoint position
●
Op. time warning
●
Wrn controls temp.
●
Time not set
●
RTC voltage
●
PVST fault
●
PVST abort
●
Wrn no reaction
●
Wrn FOC
●
Wrn FO cable budget
●
Wrn FOC connection
●
Torque wrn OPEN
●
Torque wrn CLOSE
●
SIL fault
●
PVST required
●
Maintenance required
●
FQM fail safe flt
●
Speed reduction
●
AUMA warning 2
Warnings (Cgg)
144
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profinet
