Mounting Instructions
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 14
1A
1B
3B
4B
4C
2B
2A
For information on
hole dimensions for
brackets, refer to
chapter 5.
For adequate access to the inside of the
panel when the door is opened, make
sure that the distance between the
panel’s left side (front view) and the
adjacent wall is approximately 30 cm.
