7. Mounting Drawings
7.1 Hole Dimensions - Mounting Bracket for BS-210 and
BS-211
The Operator Panel BS-210 (an integrated part of the Fire Alarm
Control Panel BS-200) can be surface mounted onto a bracket on
the wall outside the Fire Alarm Control Panel’s cabinet.
34
194.2
152
252.3
171
69.5
