Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 49
9.12.1 Terminal Points – Overview
BUR-200
MIMIC
DRIVER
Switch S2
Mode switch
With external power without fault
output: mount a strap between
terminals 1 and 2 on connector J12
Without external power: mount a strap
between terminals 1 and 2 on connector
J12
When OK: K1 is closed (between J12.1
and J12.2)
When fault: K1 is open (between J12.1
and J12.2)
J12
Pwr. LED+24V 6
Pwr. LED out 5
