Autronica Autroprime Installation Handbook

Cable Connections
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 28
9.3 Battery Connections






 Connect the black cable from the connector on the main board to
the minus pole (black) on the battery on the left side.
 Connect the red battery cable to the plus pole (red) on the battery
on the right hand side.

Red wire to plus pole + Black wire to minus pole -
NOTE: For specific information on the
installation and cable connections for maritime
installations, refer to chapter 10.
