Cable Connections
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 29
Fasten the temperature sensor to the battery with a piece of tape
as shown.
 Connect the internal temperature sensor cable to the correct
terminal points.
 Interconnect the other plus pole and minus pole on the batteries
with the cable delivered with the cabinet.
Plus pole + Minus pole -
Temperature
Sensor
