9.9.3 Connections (J4) for a cabinet with integrated BS-210 and
external panel bus
If the cabinet has an integrated operator panel BS-210 and an
external panel bus (with additional panels) is to be connected to
the cabinet, the Auxiliary terminal connector J4 must be used.
J13.1. 24VIN1
J13.2. 0VIN1
J13.5. A_2
J13.6. B_2
J14.7. GND
J13.3. 24VIN2
J13.4. 0VIN2
J4.1. O.P. +24V 1
J4.2. O.P. 0V 1
J4.3. O.P. A 1
J4.4. O.P. B 1
J4.5. O.P. +24V 2
J4.6. O.P. 0V 2
J4.7. O.P. A 2
J4.8. O.P. B 2
J4.9. Panel Bus In A
J4.10. Panel Bus In B
J4.11. Panel Bus Out A
J4.12. Panel Bus Out B
J14.1. 24VIN1
J14.2. 0VIN1
J14.5. A_1
J14.6. B_1
J14.7. GND
J14.3. 24VIN2
J14.4. 0VIN2
J7.1. Output +24V
J7.2. Output 0V
J7.3. Output A
J7.4. Output B
BS-210 BSA-200A
Cabinet with integrated BS-210, external panel bus
To external panels
Note:
From the factory, the configuration is by default prepared for a
standalone panel with integrated BS-210.
If the cabinet has an integrated BS-210 and an external panel
bus is to be connected to the cabinet, the configuration of the
panel has to be changed during commissioning in order to
achieve redundancy and fault monitoring of the panel bus.
Configuration change for panels on a panel bus:
The configuration of the panel connection (Service
Menu/System Settings/“Set Operator Panel connection”) must
be set to “J4, Auxiliary terminal block” (connector J4) during
commissioning/reconfiguration.
