Maritime Installations
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 55
10.2.2 Detection Loop Connections – Extended Terminal Block
1
Detection
Loop 3 out +
For
connection
of
Max 127
detectors/
loop units
2
Detection
Loop 3 out -
3
Detection
Loop 3 in +
4
Detection
Loop 3 in -
5
Detection
Loop 4 out +
For
connection
of
Max 127
detectors/
loop units
6
Detection
Loop 4 out -
7
Detection
Loop 4 in +
8
Detection
Loop 4 in -
1
2
3
4
5
6
7
8
