Autronica Autroprime Installation Handbook

Changes on the Detection Loop
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 77
14.3 Remove a unit and insert another unit of the
same type
Scenario during normal operation /
actions to be carried out
Panel indication (visual/audible)
For example, remove an optical smoke detector BH-300 and insert another optical smoke detector
BH-300.
1 Remove the detector from its base. Observe fault warnings “Open Circuit in negative wire” and
“Loop Unit not responding”
2 Acknowledge all faults. Buzzer off, indicator to steady
3 Insert another detector of same
type in the base.
Observe fault warning
“Loop Unit Replaced”
4 Acknowledge the fault. Buzzer off, indicator to steady
5 In service menu, select System
Settings/Save Configuration, then
Restart System.
After restart of system observe quiescent condition on panel.
14.4 Remove a unit and insert another unit of a
different type
Scenario during normal operation / actions to be
carried out
Panel indication (visual/audible)
For example, remove an optical smoke detector BH-300 and insert a heat detector BD-300.
1 Remove the detector from its base. Observe fault warnings “Open Circuit in negative wire”
and “Loop Unit not responding”
2 Acknowledge all faults. Buzzer off, indicator to steady
3 Insert a detector of a different type in the base. Observe fault warnings
“Unit Replaced. Transfer Config?”
“Configuration mismatch”
4 Acknowledge the faults. Buzzer off, indicator to steady
5 Enter service mode.
Select fault warning
“Loop Unit not responding” .
6 Select function “Remove Unit from
Configuration”.
7 Select the fault warning: “Unit Replaced.
Transfer Config.”
8 If you want to keep the previous properties,
select the function “Transfer Config” (the name
and zone and control functions will be
transferred).
If you want to change the properties, select unit
configuration in this menu instead.
9 Configure the class settings manually.
10 In service menu, select System Settings/Save
Configuration, then Restart System.
After restart of system observe quiescent condition on
panel.
