Page #67 background imageLoading...
Page #67 background image
Switches and Indicators on
the Main Board
Installation Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-INSTAL/DGB, Rev. C, 2016-29-02,
Autronica Fire and Security AS
Page 67
12.3 Dip-switches for Mode Settings (S2)
Switch Description Default
S2.1 Boot select, if ON, boot from external memory, if OFF
boot from internal boot ROM. In normal operation set
to On.
ON
S2.2 Not in use. OFF
S2.3 Run without batteries OFF
S2.4 Market selection. Select between Land (BS-200) and
Maritime (BS/200M)
Land: S2.4 ON
Maritime: S2.4 OFF
ON
S2.5 ON: disable Deep Discharge function (relay always
kept closed). Refer to chapter 12.5.
OFF
12.4 Battery Short-circuit Protection
The battery circuit is protected with an automatic resettable
electronic fuse that prevents system shutdown in case of short-
circuit in the battery circuit.
Internal Cabling
Connector Description Power Supply
J3.1 Charge Control VCON
J3.2 Charge Control FB -V
J3.3 Mains OK PSF
J3.4 Battery Temperature
Sense +
Battery
Temperature
Sensor
J3.5 Battery Temperature
Sense -
J1.3 Charger +24V +V
J1.4 Charger 0V -V
