A-2 System Administrator’s Guide
Shipping Weight: 38 lb. (17.3 kg)
Power Source: 90-264 V
AC
with autoselect 50/60Hz
Operating Limits: Thermal Transfer (ribbon): 40° to 95°F (4° to 35°C)
Thermal Direct: 40° to 104°F (4º to 40°C)
Storage: 15°F to 120°F (-10°C to 49°C)
Humidity: 5% to 90% non-condensing
Memory: 64MB RAM; 32MB Flash
Processor: 400 MHz
Printhead: Thermal at 4.09 inches (103 mm) wide
203 dpi (8.0 dots per mm)
Printing Method: Thermal Transfer (ribbon) or Thermal Direct
Print Speed: 2.5 ips default for all serial bar codes,4.0 ips, 6.0 ips, 8.0 ips,
10.0 ips, or 12.0 ips
Max Print Area: 4.09 inches x 16.0 inches (103 mm x 406 mm) with 203 dpi
4.09 inches x 12.0 inches (103 mm x 305 mm) with optional 300 dpi
RFID: 902 – 928 MHz frequency range (FCC)
865.6 – 867.6 MHz frequency range (ETSI)
the radio operates within the frequency range in accordance with
local rules and regulations.
Supplies (Media)
Contact your Sales Representative for supply recommendations in high temperature
and/or high humidity environments.
Supply Widths: 0.75 inches (19 mm) minimum for labels and tags
4.32 inches (108 mm) maximum for labels and tags
Supply Lengths: 0.32 inch (8 mm) minimum for non-indexed (continuous) supply
0.50 inch (13 mm) minimum for die cut/black mark/aperture supply
1.50 inches (38 mm) for peel mode
17.5 inches (444.5 mm) maximum for labels and tags
16 inches (406 mm) maximum;
12 inches (305 mm) maximum with optional 300 dpi
0.75 inch (19 mm) minimum for tags
1.2 inches (30 mm) minimum for cutting tags
Total Thickness: 5.6 to 14 mils
5.6 to 12.2 mils with the optional cutter
5.6 to 13.2 mils with RFID
Max. Roll Diameter: 9.375 inches (238 mm)
Supply Core: 3.0 inches (76 mm) minimum
4.0 inches (101.6 mm) maximum
