Specifications & Accessories A-3
String Tags
Widths: 0.90 inches (23 mm) minimum
2.0 inches (51 mm) maximum
Lengths: 0.78 inch (20 mm) minimum
2.0 inches (50 mm) maximum
Thickness: 5.6 to 14 mils
String Loop Length: 0.63 inches (15.8mm) minimum
1.5 inches (38 mm) maximum
String Orientation: Facing operator
Wind Direction: Face out
Ribbon
Do not leave ribbon in sunlight, high temperatures or humidity.
Ribbon Type: Standard (wax, high speed)
Premium (wax resin, TUFF-MARK® resin)
Ribbon Widths
Use with Maximum supply width
1.5 inches (38 mm) 1.3 inches (33 mm)
1.8 inches (46 mm) 1.5 inches (38 mm)
2.3 inches (58 mm) 2.0 inches (51 mm)
3.3 inches (84 mm) 3.0 inches (76 mm)
4.3 inches (110 mm) 4.0 inches (102 mm)
Note: Use a ribbon wider than your supply.
Ribbon Length: 23,600 inches (600 meters)
Cable Pinouts
The following tables show the connector pins for the serial 9-pin to 9-pin (126716) cable.
9-Pin (M) To 9-Pin (F)
SHIELD SHIELD
1 1
RCV 3 3 RCV
TX 2 2 TX
CTS 6 6 CTS
RTS 4 4 RTS
DTR 8 8 DTR
DSR 7 7 DSR
+5V 9 9 +5V
SGND 5 5 SGND
