10
Aesculap
®
ELAN 4 electro Standard handpiece (1 ring) GA861 to GA864 / ELAN 4 electro
HD handpiece (2 ring) GA865 to GA869
7.6 Manual cleaning with immersion disinfection - applied part
D–W: Drinking water
RT: Room temperature
*Recommended: BBraun Helizyme
**Recommended: BBraun Stabimed
► Follow the instructions for use of the ELAN 4 rinsing devices and rins-
ing adapters TA014447 and TA014448.
► Do not clean the applied part in an ultrasound bath.
Phase I
► Clean the product under running water, using a suitable cleaning brush
until all visible residues have been removed from the surfaces.
► Mobilize non-rigid components, such as release button, unlocking
sleeve, etc. during cleaning.
► Rinse the applied part through the rinsing adapter GB698R at least
3 times for 5 seconds with a water gun.
Phase II
► Using a disposable syringe, fill the inside of the applied part with
cleaning solution through the rinsing adapter GB698R.
► Place the applied part, with rinsing adapter connected, fully in enzy-
matic cleaning solution for 5 minutes.
Phase III
► Rinse the entire product (all accessible surfaces) under running water.
► Mobilize non-rigid components, such as release button, unlocking
sleeve, etc. during rinsing.
► Rinse the applied part through the rinsing adapter GB698R at least
3 times for 5 seconds with a water gun.
Phase IV
► Prior to manual disinfection, allow rinsing water to drain off the prod-
uct for a sufficient length of time and use compressed air to blow all
liquid out of the product through the rinsing adapter GB698R in order
to prevent dilution of the disinfecting solution.
► Using a disposable syringe, fill the inside of the applied part with dis-
infectant solution through the rinsing adapter GB698R.
► Place the applied part, with rinsing adapter connected, fully in disin-
fectant solution for 15 minutes.
Phase V
► Rinse the entire product (all accessible surfaces) under running water.
► Mobilize non-rigid components, such as release button, unlocking
sleeve, etc. during cleaning.
► Rinse the applied part through the rinsing adapter GB698R at least
3 times for 5 seconds with a water gun.
Phase VI
► Dry the product in the drying phase with suitable equipment (e.g. cloth,
compressed air).
► After manual cleaning/disinfection, check visible surfaces visually for
residues.
► Repeat the cleaning/disinfection process if necessary.
Phase Step T
[°C/°F]
t
[min]
Conc.
[%]
Water
quality
Chemicals
I Pre-cleaning RT (cold) - - D–W –
II Cleaning RT (cold) >5 1 D–W pH-neutral, pH ~ 9*
III Intermediate rinse RT (cold) - - D–W -
IV Disinfection RT (cold) >15 2 D–W Concentrate-free, aldehyde-free, phenol-free, QUAT-free, pH ~ 9**
VFinal rinse RT (cold) - - D–W -
VI Drying RT - - - -
