5
4. Product description
4.1 Available sizes
Note
The shaft length can be seen on the shaft of the drill handpiece.
ELAN 4 electro Standard handpiece (1 ring)
ELAN 4 electro HD handpiece (2 ring)
4.2 Package includes
ELAN 4 electro Standard handpiece (1 ring)
ELAN 4 electro HD handpiece (2 ring)
4.3 Components required for operation
■ Operation-ready ELAN 4 electro control unit GA800, see TA014401
■ ELAN 4 tool (1 ring or 2 ring)
4.4 Operating principle
Note
The ring marking 2 shows the shaft diameter of the tool to be used. ELAN 4
tools can be only coupled to the applied part if the ring markings
(1 ring/2 ring) of the applied part and tool match.
The drill handpiece is fitted with an ELAN 4 tool coupling (1 ring or 2 ring).
It is used with ELAN 4 electro foot controls/manual controls.
With the drill handpiece, the coupled tool rotates at the set motor speed.
The motor speed of the drill handpiece can be adjusted continuously by
the manual/foot control.
The drill handpiece can be operated in right or left (clockwise or counter-
clockwise) rotation mode.
5. Preparation
Non-compliance with these rules will result in complete exclusion of lia-
bility on the part of Aesculap.
► Do not use products from open or damaged sterile packaging.
► Prior to use, inspect the product and its accessories for any visible
damage.
► Use the products and their accessories only if they are in perfect tech-
nical condition.
Art. no. Length of shaft
GA861 L4 (approx. 4 cm)
GA862 L7 (approx. 7 cm)
GA863 L10 (approx. 10 cm)
GA864 L13 (approx. 13 cm)
Art. no. Length of shaft
GA865 L7 (approx. 7 cm)
GA866 L10 (approx. 10 cm)
GA867 L13 (approx. 13 cm)
GA868 L17 (approx. 17 cm)
GA869 L22 (approx. 22 cm)
Art. no. Designation
GA861–GA864 ELAN 4 electro Standard handpiece (1 ring)
TA014443 Instructions for use of ELAN 4 electro Standard
handpiece (1 ring) GA861 to GA864 /
ELAN 4 electro HD handpiece (2 ring) GA865 to
GA869 (leaflet)
Art. no. Designation
GA865–GA869 ELAN 4 electro handpiece HD (2-Ring)
TA014443 Instructions for use of ELAN 4 electro Standard
handpiece (1 ring) GA861 to GA864 /
ELAN 4 electro HD handpiece (2 ring) GA865 to
GA869 (leaflet)
