Aesculap
®
ELAN 4 electro Standard handpiece (1 ring) GA861 to GA864 / ELAN 4 electro
HD handpiece (2 ring) GA865 to GA869
Mechanical alkaline cleaning and thermal disinfection
Machine type: single-chamber cleaning/disinfection device without ultrasound
D–W: Drinking water
FD–W: Fully desalinated water (demineralized, low microbiological contamination: drinking water quality at least)
*Recommended: BBraun Helimatic Cleaner alkaline
► Place the tools in the correct position in the tool holder 10 of the
ECCOS holder GB718R, see Fig. C.
► Check visible surfaces for residues after mechanical cleaning/disinfect-
ing.
7.9 Inspection, maintenance and checks
► Allow the product to cool down to room temperature.
► Inspect the product after each cleaning and disinfecting cycle to be
sure it is: clean, functional, and undamaged.
► ELAN 4 electro Connect oil spray adapter GB600860 (gray) to connec-
tor for motor cable 3 and spray through the applied part for approx.
2 seconds with Aesculap-STERILIT oil spray GB600, see Fig. D.
► Check the product for any damage, abnormal running noise, overheat-
ing or excessive vibration.
► Inspect tools for broken, damaged or blunt edges.
► Set aside the product if it is damaged.
7.10 Packaging
► Always follow the instructions for use of the respective packaging and
storage devices (e.g. instructions for use TA009721 for Aesculap-
ECCOS holder system).
► Place the applied part in the correct position in the ECCOS holder
GB082R/GB083R, see Fig. B.
► Place the tools in the correct position in the ECCOS holder GB718R, see
Fig. C.
► Pack trays appropriately for the intended sterilization process (e.g. in
Aesculap sterile containers).
► Ensure that the packaging will prevent a recontamination of the prod-
uct.
Phase Step T
[°C/°F]
t
[min]
Water
quality
Chemicals
I Pre-rinse <25/77 3 D–W -
II Cleaning 55/131 10 FD–W
■ Concentrate, alkaline:
–pH ~ 13
– <5 % anionic surfactant
■ 0.5 % working solution
–pH ~ 11*
III Intermediate rinse >10/50 1 FD–W -
IV Thermal disinfection 90/194 5 FD–W -
VDrying - - - In accordance with the program for the cleaning and disinfecting machine
