Technical data
03|2022 EN 57
10 Technical data
Circuit board
microprocessor controlled
Operating voltage
1~ 230 V, 50 Hz
Connection value (motor
capacity P
1
)
max. 1.00 kW
Fuse, only for actuator/pump
315 mA delay/4 A delay
Operating pressure
max. 2 bar
10.1 Dimensional drawing
The design shown is a BADU OmniTronic with BADU Mat R41.
Dimensions in brackets ( ) are for the BADU OmniTronic with
BADU Mat R51
