3.1.5 Audio signals
Each touch of a key is acknowledged with an acoustic signal.
Further audio signal sequences represent certain conditions,
warnings or alarms.
Number signal
Meaning
1x
Keyboard actuation
2x
Start of a manual or automatic backwash or
filter process
3x
Refill on/off in level control
4x
Manual drain
5x
Error message: Safety time in level control
expired; status error; sensor error; time error
3.1.6 LED display
Colour LED
Meaning
orange
Level refill
red + blue
Gear motor, forwards
red + blue + white
Gear motor, reverse
red
Filter pump, on
green
Switching position z1-z2
yellow
Switching position z7-z8
Colour LED level display
Meaning
blue
Water level OK
