Description
03|2022 EN 21
No functions should be overloaded. The
optional additional floor drain board (material
no. 2606402204) can be used for using relay
R_x. The connection as relay R_x is
described in the enclosed installation
In the Info menu, details regarding the
firmware and the manufacturer can be
found.
Pos: 36.20. 1 /Technische D okumentation S peck Pumpen /Betriebsanleit ung/Beschreibu ng/BADU Omnitr onic_ BADU Om ni Stell an trie b/Sta tus- Anzeigen/Stat us-Anzeige @ 17\mod_158324322 9228_370.docx @ 329375 @ 3 @ 1
3.2.1 Status displays
Current position
Speeds can be N0, N1, N2 or N3.
This display becomes an alternating display as soon as an
additional function with temperature processing is connected. In
this case, the temperature at DC4 (pool water) and briefly also the
temperature at DC5 (Solar) are displayed.
BADU OmniTronic
Firmware V3.74
+49 9123 949 0
SPECK Pumpen
