Balluff BTL5 Series User Manual

4 english
1.1 Validity
This guide describes the construction, function and setup
options for the BTL5 magnetostrictive linear position
sensor with digital interface. It applies to models
BTL5-P/I/L/M1-M ____ -H/W(8) -S32/KA __ /K __ (see
type code on page17).
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the BTL.
1.2 Symbols and conventions
Individual instructions are indicated by a preceding
triangle.
► Instruction 1
Action sequences are numbered conutively:
1. Instruction 1
2. Instruction 2
Note, tip
This symbol indicates general notes.
1.3 Scope of delivery
– BTL
– Condensed guide
The magnets are available in various models
and must be ordered separately.
1.4 Approvals and markings
UL approval
File no.
E227256
US Patent 5923164
The US patent was awarded in connection with this
product.
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive.
The BTL meets the requirements of the following product
standard:
– EN61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN55011
Noise immunity tests:
– Static electricity (ESD)
EN61000-4-2
Severity level 3
– Electromagnetic fields (RFI)
EN61000-4-3
Severity level 3
– Electrical fast transients (burst)
EN61000-4-4
Severity level 3
– Surge
EN61000-4-5
Severity level 2
– Conducted interference induced by
high-frequency fields
EN61000-4-6
Severity level 3
– Magnetic fields
EN61000-4-8
Severity level 4
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
1
Notes to the user
BTL5-P/I/L/M1-M ____ -H/W(8) -S32/KA __ /K __
Magnetostrictive Linear Position Sensor – Rod Style
