Balluff BTL5 Series User Manual

14 english
6.6 Dimensions, weights
Rod diameter 8mm or 10.2mm
Nominal length
at Ø8mm
at Ø10.2mm
25…1016mm
25…5500mm
Weight
(depends on length)
Approx. 2kg/m
Housing material Stainless steel
Flange material Stainless steel
Rod material Stainless steel
Rod wall thickness
at Ø8mm
at Ø10.2mm
0.9mm
2mm
Housing mounting via
threads
M18×1.5 or 3/4"-16UNF
BTL5-…-K__, BTL5-…-KA__
Cable material PUR;
cULus20549
80°C, 300V, internal wiring
Cable temperature –40°C…+90°C
Cable diameter Max. 6.7mm
Permissible bending
radius
Fixed routing ≥32mm
Moved ≥95mm
6
Technical data (continued)
BTL5-P/I/L/M1-M ____ -H/W(8) -S32/KA __ /K __
Magnetostrictive Linear Position Sensor – Rod Style
