R5906852 /09 F80166
Light source Laser phosphor
Light source lifetime > 20000 h in normal mode, > 12000 h in silent mode, > 40000 h in long life
mode, > 12000 h in high brightness mode
Sealed DLP™ core Yes
Orientation 360° rotation, no restrictions
3D Active stereoscopic 3D / Passive stereo compatible
Image processing Embedded warp & blend engine
Keystone correction Yes
Inputs 12G-SDI, 2x DP 1.2, 2x dual link DVI-D, HDBaseT, HDMI2.0 (HDCP2.2,
HDR10), RJ 45 Ethernet, DMX in/out, RS232 in, 2x USB, 12V out
Input resolutions Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz
refresh rates:
24Hz to 120Hz for WQXGA+ (2716x1600) and 24Hz to 60Hz for 4K/
4KUHD (4096 x 2160/ 3860 x 2400)
Software tools Projector Toolset
Control IR, RS232, RJ45, XLR wired
Network connection 10/100 Ethernet, RJ45
Power requirements 100-240V / 50-60Hz
Power consumption 950 W nominal, 1,100 W maximum
24/7 operation Yes**
BTU per hour 3,250 BTU/h nominal, 3,800 BTU/h maximum
Standby power <0.5w
Throw Ratio 0.85 - 1.06 ; 1.06 - 1.43 ; 1.43 - 2.12 ; 2.12 - 3.18
and compatible with FLD/FLD+ series (with adapter)
Noise level (typical at 25°C/
77°F)
35 dB(A)
Operating temperature 10°C (50°F)- 40°C (104°F) (up to 1500m altitude) / 10° (50°F) - 35°C (95°
F) (up to 3000m altitude)
Storage temperature -20 to 60 °C
Operating humidity 20 - 80% RH (non-condensed)
Storage - transport humidity 20 - 90% RH (non-condensed)
Dimensions (WxLxH) 480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in
Weight 25.5 kg / 56.2 lbs
Standard accessories Power cord, wireless remote control
Certifications CE, FCC Class A, cNemkoUS, CCC, EAC, KSA, RCM, UkrSEPRO
Specifications
