Barco F80-Q12 - Overview Video Timings SDI Inputs

197R5906852 /09 F80
Resolution
Vertical
refresh rate
(Hz)
Compatible signal
HDMI 2.0
Input
12G SDI
DisplayPort
1.2 Inputs
HDBaseT
Input
DVI Inputs
2048 x 1080 60 X X X X X
2048 x 1080 120 — — X — —
2560 x 1600 50 X — X X X
2560 x 1600 60 X — X X X
2560 x 1600 120 — — X — —
3840 x 2160 24 X — X X X
3840 x 2160 25 X — X X X
3840 x 2160 30 X — X X X
3840 x 2160 50 X X X — —
3840 x 2160 60 X X X — —
3840 x 2400 24 — — — — X
3840 x 2400 25 — — — — X
3840 x 2400 30 — — — — X
3840 x 2400 50 X — X — —
3840 x 2400 60 X — X — —
4096 x 2160 24 X — X X X
4096 x 2160 25 X — X X X
4096 x 2160 30 X — X X X
4096 x 2160 50 X X X — —
4096 x 2160 60 X X X — —
E.2 Overview video timings SDI Inputs
Overview
The following standard video formats are available for the projector.
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
6
Type Port Type
1280 x 720 24 HD-SDI Single Link & Quad Link
1280 x 720 25 HD-SDI Single Link & Quad Link
1280 x 720 30 HD-SDI Single Link & Quad Link
1280 x 720 50 HD-SDI Single Link & Quad Link
1280 x 720 60 HD-SDI Single Link & Quad Link
1920 x 1080 24 HD-SDI Single Link & Quad Link
Overview video timings for video interfaces
6. Support for refresh rates 24.00, 30.00 and 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.
