R5906852 /09 F80178
B.1 Specifications DVI-I inputs
Specifications
Parameter Value
Connector DVI- I female digital RGB ( DVI-D functionality)
Signal characteristics DVI 1.0, Digital, TMDS
Max. cable length 25 m (24 AWG)
Max. pixel rate 330 MHz (dual link), 165 MHz (single link)
Scan format Progressive
Max. input data resolution 1920x1200 60Hz (Single link)
2560x1600 60Hz (Dual Link)
1920x1200 @120 Hz (Dual link)
1920x2400 @60Hz
Bit depth 8 bit
EDID Supported
HDCP Supported
B.2 Specifications DisplayPort 1.2 inputs
Specifications
Parameter Value
Connector Standard DisplayPort
Signal characteristics DP 1.2
Functionality Mandatory
Max. cable length 2 m (24 AWG) - RBR;
2 m (24 AWG) – HBR1, HBR2
Supported Link Rate RBR, HBR1, HBR2
Scan format Progressive
Max. input data resolution 2716x1600@120Hz (WQXGA+) max
3840x2400 @60Hz (4K ) max
Bit depth 8, 10, 12 bit
EDID Supported
HDCP Supported
B.3 Specifications HDMI 2.0
Specifications
Regarding HDMI 2.0: The decryption protocol HDCP 2.2 are enabled and valid in this unit.
Connector specifications
