R5906852 /09 F80180
Parameter Value
70 m (Cat5e/6), Pixel Clock >225HHz, Video
Datarate >5.3Gbps
100 m (Cat6a/7), Pixel Clock >225HHz, Video
Datarate >5.3Gbps
Max TMDS Clock Frequency 270 MHz
Max video resolution supported 4096x2160 @30Hz
HDCP Pass-Through Yes, from Source to Projector
IR Extension Not Supported
RS-232 Extension Not Supported
10/100Mbps Ethernet Pass-Through Not Supported
Fallback to 100BaseTx, IEEE 802.3u Not Supported
USB Over Centre Tap Not Supported
Power Over Ethernet Not Supported
Audio Not Supported
LEDs - HD Base Status Operation: Green, Left
Link/Mode: Yellow, Right
B.6 High-bandwidth Digital Content Protection
(HDCP)
About HDCP
HDCP protocol is a form of digital copy protection to prevent copying of digital audio & video content as it
travels across connections.
Capability of a connector to accept HDCP content (revision v1.X or v2.X) can vary and depends of the FPGA
resource mapping that manage connectors. Please refer to the Home/Source menu to obtain this information.
Connector specifications
