Page #168 background imageLoading...
Page #168 background image
R5906852 /09 F80168
3D Active stereoscopic 3D / Passive stereo compatible
max WQXGA @120Hz
Keystone correction Yes
Inputs HDMI2.0 (HDCP2.2, HDR10) / 2x DP 1.2 / 12G-SDI /2x dual link DVI-D /
HDBaseT / RJ 45 Ethernet / DMX in-out / RS232 in / 2x USB / 12V out
Input resolutions Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz
refresh rates:
24Hz to 120Hz for WQXGA+ (2716x1600) and 24Hz to 60Hz for 4K/
4KUHD (4096 x 2160/ 3860 x 2400)
Software tools Projector Toolset
Control IR, RS232, RJ45, XLR wired
24/7 operation Yes**
Network connection 10/100 Ethernet, RJ45
Power requirements 100-240V / 50-60Hz
Power consumption 1050 W nominal, 1200 W maximum
Standby power < 0.5W
Noise level (typical at 25°C/
77°F)
35 dB(A) when used in silent mode / 39 dB(A) in normal mode
Operational ambient
temperature
0°-35°C / 32°-95°F
Storage temperature -20 to 60 °C
operation humidity no
condens
0%-80%
Storage humidity 20 - 90% RH (non-condensed)
Dissipation BTU max 4100 BTU/h
Dimensions (WxLxH) 480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in
Weight 26.8 kg / 59.1 lbs (without lens)
Shipping dimensions
(WxLxH)
583 x 784 x 444 mm / 23.0 x 30.9 x 17.5 inch
Shipping weight 38.5 kg / 81.6 lbs
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1
complies with FCC rules & regulations, part 15 Class A and CE EN55022
Class A, RoHS
Warranty Limited 3 years on parts and labor(***)
Extendable up to 5 years.
Notes * When measured with the GLD 1.43-2.12:1 lens in Wide Angle
** For optimal performance, switch off the projector regularly. For details
please consult the manual.
*** Except on light source: 20,000 hours in normal mode, or 3 years,
whichever comes first.
Specifications
