27R5906852 /09 F80
2
ECO
READY
ON
1%
50%
50%
JSON
ON
OFF
JSON
ON
ECO
JSON
ON
ECO
ASCII
ON
Stby
ASCII
ON
Powr
JSON
ON
ON
Image 2–5
-
Projector mains powered
-
Auto transition after x minutes if ECO mode enables
-
Press power On/Off button, remote On/Off button
-
Wake on LAN (WOL)
-
JSON command (Power on, Power off, Go to Eco)
-
ASCII command (power, stby) received via RS-232
Power on projector
If not already connected, connect the female side of the power cord with the power input socket of
the projector. For more details see section dedicated to the power cord installation.
The background image of the startup screen and info screens can be changed with Projector
Toolset with an installed F80 plug-in.
Plug the 3-prong plug of power cord into a grounded AC outlet. The projector will go to READY mode. During
this stage the system boots and performs the internal check of the boards. The Power On/Off button will
BLINKING WHITE until READY mode is achieved. Once in READY mode, the Power On/Off button will be lit
WHITE.
Going from READY to ON
Press the Power On/Off button (short press) on the projector, or the Power On button on the remote control.
The projector will power ON. The Power On/Off button will BLINK BLUE during the transition from READY to
ON. Once the projector is on, the Power On/Off button will be lit BLUE.
A JSON command (power on) could also be send to make the projector turn in to ON mode.
Going from ON to READY
Press and hold the Power on/off button on the projector for 3 seconds, or press the Power Off button on the
remote control. The projector will power down through a cool down phase. The Power on/off button will BLINK
WHITE during the transition from ON to READY. Once the projector is in READY, thePower on/off button will
be lit WHITE.
A JSON command (power off ) could also be send to make the projector turn in to READY mode.
Getting Started
