R5913197 /02 SP2K-S108
10.1 Opening the sealed compartment
This procedure assumes that the side and top cover have been removed.
CAUTION: This procedure may only be done by a qualified and trained service technician.
Required tools
Torx screwdriver T20
How to open the sealed compartment
1. Remove the two screws (reference 1) holding the side cover. Use a T20 Torx screwdriver.
Image 10–1 Sealed cover fixation
2. Lift up the cover and remove it from the projector.
