6.3 ICP-D (Integrated Cinema Processor – Direct)
In case the projector is equipped with a Barco ICMP-X no ICP-D board is inserted. All ICP-D
functionality is integrated in the Barco ICMP-X.
Introduction
Depending on the projector configuration, the projector card cage is either equipped with an ICP-D or ICMP-X.
In case an ICP-D is installed, then a third-party IMB or IMS can be inserted into the slot below the ICP-D.
ICP-D functions
• Stores a part of the projector files (screen files, MCGD files, ...).
• Stores the license files related to HDMI inputs.
Note: the License file related to the use of ICP-D with a third party Integrated Media Block (IMB) is not
stored here.
• Stores and generates test patterns.
• Scaling to native resolution, re-sizing, masking, line-insertion de-interlacing, color space conversion, de-
gamma, color correction.
• Source Selection between alternative content and cinema content.
• Contains a real time clock, which must be synchronized with the GMT/UTC time stored in Integrated Media
Block.
• Handles unpacking of special video formats.
License
On Series 4 projectors, a license based on the projector serial number and the brand of the IMB is needed.
This means a new license is required in case you change projector or IMB brand.
On Series 2 projectors, no license is needed in order to use ICP-D together with an third party IMB.
Supported IMBs from ICP-D software version 1.2.0.5 (included in the Series 4 software 1.4.0) onwards:
• Dolby ShowVault/IMB: From software version 2.8.25 onward
• Dolby IMS3000: From software version 3.3.26 onward
• Dolby IMS2000: From software version 2.8.25 onward
• GDC SX4000: From software version 10.00 (build 103) onward
• GDC SR1000: From software version 17.20 (build 201) onward
• QSC CMS-5000: From software version 1.1.01818+ onward
• Qube Xi: From software version 3.0.1.40 onward
• CMC CineCloud: From software version 1.2.2 onward (Series 2 only)
On series 2 projectors, starting from ICP-D software version 1.2.0.10, HD-SDI + Enigma as well as Quad 3G/
SDI + Enigma are now supported. All media server that connect to the HD-SDI + Enigma board and that don’t
require CineCanvas are now supported.
This list is subject to change. Please contact Barco service to obtain the updated list of supported
IMB brands (models, minimum software version, etc).
Contact the supplier of your IMB to acquire a valid license.
Grace period
Series 4 projectors equipped with an ICP-D are delivered from the factory with a grace period of 200 hours.
This means that the projector can be used (in “On” mode) with a third party IMB for 200hrs. During this period
the projector trigger a Warning (orange notification) with the time remaining in the description. The projector
will go into Error status (red notification) if no valid license is installed within the specified timeframe. In this
case the media server can no longer be selected.
