R5913197 /02 SP2K-S110
10.2 Closing the sealed compartment
Required tools
Torx screwdriver T20
How to close the sealed compartment
1. Place the top cover on the light processor compartment as illustrated.
Image 10–4
2. Slide the top cover wards on the lips until it is in its correct position.
Image 10–5
3. Place the side cover. You need slide the cover downwards on both lips until it is in its correct position (take
care to hook the cover onto the studs).
Convergence
