33R5913197 /02 SP2K-S
2.5 Air flow of the projector
Air flow
The SP2K-S projector has three air inlets and one air outlet. The air inlets are located on the front side the left
side and bottom side of the projector. The air outlet are located on the back side of the projector.
Take into account the location of the air inlets and outlets when determining a suitable location to install the
projector. Make sure that when installed, the hot air coming from the air outlets is not automatically sucked
back in via the air inlets.
Image 2–8
1 Air inlet front of the projector
2 Air inlet bottom side of the projector
3 Air inlets left side of the projector
4 Air outlet back of the projector
Getting started
