12.1 Removal of the left side cover .....................................................................................................128
12.2 Removal of the front cover...........................................................................................................129
12.3 Removal of the rear filter cover .................................................................................................... 131
12.4 Removal of the entire rear cover ................................................................................................. 132
12.5 Removal of the right side cover ................................................................................................... 133
12.6 Removal of the operator side cover ............................................................................................. 134
12.7 Removal of the top cover ............................................................................................................ 135
12.8 Mounting the top cover ............................................................................................................... 136
12.9 Mounting the operator side cover ................................................................................................ 137
12.10 Mounting the right side cover ......................................................................................................139
12.11 Mounting the rear cover .............................................................................................................. 140
12.12 Mounting the rear filter cover .......................................................................................................141
12.13 Mounting the front cover.............................................................................................................. 142
12.14 Mounting the left side cover ......................................................................................................... 143
About this chapter
Most installation, maintenance and service procedures demand removing one or more of the projector covers
to gain access to the parts to maintain or to service. To avoid redundancy, all procedures about cover
removing or installing are grouped together in this chapter. The maintenance and servicing procedures also
refer to this chapter if required. The procedures in this chapter describe, with detailed step by step actions and
illustrations, how to remove or install the projector covers. Note that the covers may only be removed by
qualified service personnel.
WARNING: All procedures described in this chapter may only be performed by TRAINED
PROJECTIONISTS or qualified SERVICE PERSONNEL.
WARNING: Always switch off the projector and unplug the power cord before removing one of the
covers, unless otherwise stated.
Projector covers 12
