12.14 Mounting the left side cover
How to mount
1. Place the cover over the cover hook on the bottom of the projector frame (reference 1).
1
Image 12–26 Left side cover positioning
2. Tip forward the cover over the hooks (reference 2) in the top of the frame, then push lightly to lock the
handles (reference 3) on the hooks.
2
3
Image 12–27 Left side cover locking
