12.3 Removal of the rear filter cover
If the rear cover is the only cover you need to remove (e.g. when checking / replacing the filter),
there is no need to turn off the projector.
Required tools
No tools required.
How to remove
1. Unlock the cover from the frame by pushing plastic hooks in handles.
Tip: A tool such as a flat screwdriver can be used to more easily unlock the locked handles.
Image 12–5 Rear filter cover unlocking
2. Tilt the upper side of the cover outwards, then lift up the cover and remove it.
Image 12–6 Rear filter cover removing from the projector
