Barco SP2K-S

25R5913197 /02 SP2K-S
Altitude (m) Altitude (ft)
Maximum Power
(%) (15S model
only)
Maximum ambient
Temp (°C)
Maximum ambient
Temp (°F)
3 000 9 900 90% 35 95
4 000 13 200 80% 35 95
Main Power requirements
SP2K-S projectors operate from a single-phase power net with a protective earth ground (PE).
Power system Power requirements
single-phase power net 200-240VAC, 10A, 50-60Hz
down to 110VAC , 16A, 50-60Hz
When the projector is connected to a 120V power net, a message is displayed to notify the user that
the input voltage is lower than expected. This will not affect the projector behavior. Only the SP2K-
11S and SP2K-15S will operate at reduced brightness.
The projector must be connected internally between a mono-phase connection. See “Connecting the projector
with the power net”, page 44.
The power cord required to connect the projector with the power net is not delivered with the projector. It is the
responsibility of the customer to provide the correct type of power cord. The cross-sectional area of the
conductors in the power supply cord shall not be less than 2.5 mm
2
(12 AWG).
The power cord must be rated for minimum 300 V.
To protect operating personnel, the National Electrical Manufacturers Association (NEMA) recommends that
the instrument panel and cabinet be grounded. In no event shall this projector be operated without an
adequate cabinet ground connection.
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes
and conduit types must comply with local codes.
A readily accessible disconnect device shall be incorporated externally to the equipment for removal of the
power to the equipment mains terminals.
The building installation must be provided with a circuit breaker of max. 32 A to protect the complete unit.
WARNING: Disconnect the power to the unit mains terminals for removal of all power from the unit.
UPS requirements
The Uninterruptible Power Supply (UPS), also known as a Continuous Power Supply (CPS), must have an
output voltage of 200-240 V at 50-60 Hz and must be capable of delivering an output current of 5 A. This UPS
provides only power for the electronics and not for the light source.
The connection between the UPS unit and the UPS inlet of the projector must be done with a certified AC
power supply cord of minimum 1,50 mm² or 14 AWG and minimum 300 V.
The SP2K-S does not have a built in UPS unit.
Projector weight
Do not underestimate the weight of the SP2K-S projector. The projector weight ±69.5 kg (±152.119 lbs)
without lens. Ensure that the pedestal on which the projector is installed is capable of supporting the complete
load of the system. Minimum 4 people are needed to carry the projector.
CAUTION: An external frame must be used to stack projectors.
Getting started
