Barco SP2K-S

29R5913197 /02 SP2K-S
Image 2–5
8. Lift the projector from the wooden pallet by gripping the corner handles of the projector with both hands
and place the projector on the pedestal. Use a minimum of 4 people to lift and place the projector on the
pedestal.
Tip: The corner handles are wide enough to fit both your left (L) and right (R) hand. Only use the
handles to lift the projector.
1
L
R
Image 2–6
9. If present (depending on whether the projector comes with an Integrated Cinema Media Processor),
remove and put aside the small box containing the HDDs (reference 1).
Save the original shipping carton and packing material, they will be necessary if you ever have to
ship your projector. For maximum protection, repack your projector as it was originally packed at the
factory.
The projector is delivered with a plastic cover inside the Lens Holder. This to prevent intrusion of
dust and foreign particles.
Getting started
