How to recognize an ICMP-X
At the first glance ICMP-X is very similar to ICMP (the previous generation device) however both devices are
not fully compatible and not interchangeable. This is the reason why it is very important to ensure that you use
correct model.
Unlike the previous version the name of ICMP-X appears on the upper left side of the front face (under the
Barco logo).
Image 7–4
Location in the Card Cage
The Card Cage can be different depending the projector type but it generally consists of a button module and
several removable units, which include the ICMP-X (reference 1) and the Barco Cinema Controller (reference
2).
ICMP-X location in the Card Cage of an SP4K and SP2K series projector.
Image 7–5
ICMP-X
