Barco SP2K-S

83R5913197 /02 SP2K-S
Situation Solution
Result: As soon the new HDD is detected by the
ICMP-X the rebuild of the RAID is started (Blinking
red LED).
Multiple disks failed (multiple red LEDs) + Error
10573 “The RAID is broken”.
Note: The disk status (RAID broken) can be
retrieved via the (Web) Commander. See user guide
of the (Web) Commander.
1. Switch off the power.
2. Replace all defect HDDs with approved models of
the same storage capacity. See procedure
“Removing a HDD from the ICMP-X”, page 89,
and “Installing a HDD into the ICMP-X”, page 90.
Ensure to insert the HDDs firmly.
3. Switch on the power.
4. Start “RAID Initialize”. See user guide of the
(Web) Communicator.
Result: a new empty RAID is created.
All HDD LEDs remain off + Error 10580 “local
storage not available”.
Note: The disk status (Error code) can be retrieved
via the (Web) Commander. See user guide of the
(Web) Commander.
1. Switch off the power.
2. Reseat all HDDs. See procedure “Removing a
HDD from the ICMP-X”, page 89, and “Installing a
HDD into the ICMP-X”, page 90. Ensure to insert
the HDDs firmly.
3. If problem remains try “RAID Initialize”. See user
guide of the (Web) Communicator. Note that all
content will be lost!
4. If problem remains contact Service for further
instructions.
In case the ICMP-X has to be returned to factory (e.g. for repair) the non defective HDDs should be
removed and kept.
ICMP-X
