Specifications, Requirements, and Precautions AW00123409000
10 Basler ace USB 3.0
Specification acA1300-200um acA1300-200uc
Resolution (H x V pixels) 1280 x 1024 (full resolution)
Sensor Type
ON Semiconductor
®
PYTHON NOIP1SN1300A
Progressive scan CMOS
Global shutter
ON Semiconductor
®
PYTHON NOIP1SE1300A
Progressive scan CMOS
Global shutter
Optical Size 1/2"
Effective Sensor Diagonal 7.9 mm
Pixel Size (H x V) 4.8 µm x 4.8 µm
Max. Frame Rate
(at full resolution)
203 fps (at fast sensor readout; see Section 1.2 on page 2)
169 fps (at normal sensor readout)
Mono/Color Mono or color (color cameras include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono 8 Mono 10p
Mono 10
Mono 8 RGB8
Bayer BG 8 BGR8
Bayer BG 10 YCbCr422_8
Bayer BG 10p
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Via hardware trigger or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
Mono Models:
≈2.8 W (typical), @ 5 VDC, ≈3.1 W (max.)
Color Models:
≈3.0 W (typical), @ 5 VDC, ≈3.3 W (max.)
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL in preparation, FCC, GenICam V. 2.x (includes PFNC V.
2.x and SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the Basler website:
www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 5: General Specifications
