AW00123409000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 11
Specification acA1920-25um/uc
Resolution
(H x V pixels)
um: 1920 x 1080
uc: 1920 x 1080
Sensor Type Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1/3.7"
Effective Sensor Diagonal 4.9 mm
Pixel Size (H x V) 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
26 fps
Mono/Color Mono or color
(color cameras include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Models: Mono 8 Mono 12p
Mono 12
Color Models: Mono 8 Bayer GB 12p
Bayer GB 8 YCbCr422_8
Bayer GB 12
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
≈2.2 W (typical and max.) @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL Listed, FCC, GenICam V. 2.x (includes PFNC V. 2.x and
SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the Basler website:
www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 6: General Specifications
