Basler acA2040-55 User Manual

Features AW00123409000
240 Basler ace USB 3.0
2
0
P
1
P
Use Case: Synchronous cycling through sequencer sets, according to path 1,
cycling interrupted by synchronous reset according to path 0
Settings: Acquisition Mode = Continuous
Trigger Mode for the frame start trigger = On
Trigger Activation for the frame start trigger: Rising Edge
Frame start triggers applied externally via Line 1
Synchronous trigger source for sequencer set advance: Counter 2 End
Synchronous trigger source for reset of sequencer set advance:
GPIO line Line 3
102 2 0 10 1-1
21
11 1
11
11
1
P2 3P
Time
Line 3 (GPIO)
Trigger Source,
Path 0
= camera loads a sequencer set into the active set making it the current set
= current sequencer set that is used for image acquisition; sequencer set was just loaded
= current sequencer set that is used for image acquisition; already present in the active set
= current sequencer set that is in the active set immediately before the sequencer feature is enabled
= current sequencer set; was in the active set immediately before the sequencer feature was enabled
Sequencer
Mode Set to
On
Counter 2 End
Trigger Source,
Path 1
Frame Start
Trigger Signal
Sequencer
Mode Set to
Off
= trigger signal generated externally
= frame exposure and readout
= frame transmission
= camera is waiting for a frame start trigger
Fig. 90: Use Case 2 - Synchronous Cycling Through Sequencer Sets Based on Counter 2 End (Path 1), One Reset.
= counting of frame start triggers, counted by Counter 2 and limited by Counter Duration; number: current count
