AW00123409000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 17
* At full resolution and maximum bandwidth, see also Chapter 2 on page 59.
Specification acA2040-90um/umNIR acA2040-90uc
Resolution (H x V pixels) 2048 x 2048 2040 x 2046
Sensor Type CMOSIS CMV4000-2E5M/2E12M
Progressive scan CMOS
Global shutter
CMOSIS CMV4000-2E5C
Progressive scan CMOS
Global shutter
Optical Size 1"
Effective Sensor Diagonal 16.0 mm
Pixel Size (H x V) 5.5 µm x 5.5 µm
Max. Frame Rate* 90 fps
Mono/Mono (NIR)/Color Mono or mono (NIR) or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono 8 Mono 12p
Mono 12
Bayer BG 8 Bayer BG 12p
Bayer BG 12
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Via hardware trigger or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
≈2.9 W (typical) @ 5 VDC, ≈3.2 W (max.)
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL Listed, FCC, GenICam V. 2.x (includes PFNC V. 2.x and
SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the Basler website:
www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 12: General Specifications
