AW00123409000 Features
Basler ace USB 3.0 261
Using ROIs with Reverse X
You can use the image ROI feature when using the Reverse X feature. Note, however, that the
position of an ROI relative to the sensor remains the same regardless of whether or not the Reverse
X feature is enabled (see Figure 102).
As a consequence, an ROI will display different images depending on whether or not the Reverse
X feature is enabled.
Auto function ROIs will behave analogously to image ROIs.
For more information about auto functions, see Section 7.15 on page 294.
For color cameras, provisions are made ensuring that the effective color filter
alignment remains constant for normal and mirror images, that is, the same
alignment applies to normal and mirror images.
Fig. 102: Using an ROI with Reverse X Mirror Imaging
Normal Image Mirror Image
ROI
ROI
